Description:

Features:

• 25 Horsepower
• 992 lbs. Loader Lift Capacity At Pins
• Hydro Max Transmission
• Dual HST Pedals
• 2 Range Transmission
• Additional Features
• Independent PTO
• Power Steering
• Selectable 4wd
• Diffirential lock
• 7 Year Powertrain Warranty

Specifications:

• Engine (1025)
• Engine Type: 3 Cylinder, Water-Cooled, Diesel
• Engine Power: 24.6 HP @ RPM
• Displacement: 77.3 cubic inches
• Number of Cylinders: 3
• Fuel Tank Capacity: 5.8 gallons
• Drivetrain (1025)
• Transmission: Hydrostatic (HST)
• Number of Speeds: 2 Range
• Clutch: None
• Brakes: Wet, Multi-Disc
• Hydraulics (1025)
• Hydraulic Type: Power Assisted Hydro-Static
• Total Hydraulic Flow:
• Power Steering + Implement: 7.0 (2.8 + 4.2)
• 25.7 (10.5 + 15.8)
• 3-Point Hitch: Cat 1
• Rear Remote Valve: Not Available
• 3-Point Hitch Lift Capacity @ 24" Behind Lift Point: 450 lbs
• Dimensions (1025)
• Overall Length: 104"
• Overall Width: 45.8"
• Overall Height: 91.3"
• Wheelbase: 57.5"
• Minimum Ground Clearance: 9.4"
• Weight: 1,638 lbs
• PTO (1025)
• PTO Type: Independent
• Rear (Mid) PTO Speed: 540 RPM
• PTO Power: 18.8 HP
• Electrical (1025)
• Battery: 12 V, 500 CCA
• Alternator: 12 V, 40 A
• Wheels & Tires (1025)
• Front Tires (IND): 23X8.50-12
• Rear Tires (IND): 12-16.5
• Loader (BBL105)
• Standard Bucket Size: 50 inches
• Maximum Lift Height: 75.5 inches
• Dig Depth: 4.6 inches
• Lift Capacity to Full Height at Pivot Pin: 992 lbs
• Breakout Force: 1,531 lbs
• Shipping Weight: 573 lbs
• Backhoe (BBH105)
• Standard Bucket Size: 12 inches
• Type: Subframe-Mounted, Quick Attach
• Maximum Dig Depth: 76 inches
• Dig Force (Bucket): 2,020 lbs
• Shipping Weight: 816 lbs
